Alfa Romeo Spider Factory Workshop Manual

• Alfa Romeo Spider Owners Manual>>
• Alfa Romeo Home Page>>

Original Factory Repair and Maintenance manual for the legendary Alfa Romeo Spider roadster. The manual contains full technical data, Electrical Diagrams, step-by-step instructions for Diagnostics and repair of all major vehicle components.

• Engine and fuel system
• Transmission and clutch
• Suspension and steering
• Brake system
• Electrical equipment and wiring diagrams
• Body and interior elements

Alfa Romeo Spider (Duetto, Series 1–4, 1966–1993)

• Body corrosion is one of the main weak points of classic Spiders. The sills, wheel arches and underbody are particularly vulnerable.
• Electrics – weak contacts, problems with ground, connector oxidation.
• Oil leaks – a classic problem with old Italian engines.
• Suspension – wear of silent blocks and ball joints, which affects handling.
• Carburetors (on early versions) – difficulties with adjustment and sensitivity to fuel quality.

🔧 Alfa Romeo Spider (916, 1995–2006)

• Electrical wiring and electronics – sensor failures, instrument cluster “glitches”, problems with the central lock.
• Suspension – rapid wear of the front arms and silent blocks.
• Roof (convertible) - leaks through seals, breakdowns of the folding mechanism.
• Twin Spark engines - stretched balance shaft chains, increased oil consumption.
• V6 Busso - reliable, but requires regular maintenance (timing belt should be changed every 60,000 km).
• Corrosion - better than the classic, but problem areas: rear wheel arches and bottom.

🔧 Alfa Romeo Spider (939, 2006–2010)

• The weight of the car is heavier than its predecessors, which affects the dynamics and suspension.
• Suspension - rapid wear of ball joints, stabilizer struts and rear multi-link suspension.
• Electrics - problems with CAN bus, sensors, comfort unit.
• Diesel versions (JTDm) - possible problems with EGR, turbine and particulate filter.
• Petrol JTS – prone to carbon deposits on valves and increased oil consumption.
• Power steering – fluid leak, weak hoses.
