Cadillac CTS (2017) – fuse box diagram

Engine compartment fuse block

Fuse Usage

1 —

2 —

3* Passenger motorized safety belt

4 —

5 —

6 Driver Power Seat

7 —

9 —

10 —

11 —

12 —

13 Passenger Power Seat

14 —

15 Passive entry/Passive start/Front wipers

16 —

17* Headlamp Washer

18 —

19 ABS pump

20 ABS valve

21* —

22 Driver motorized safety belt

26* —

27 –/Heated Seat 2

28 –/Reverse lock out

29* AFS AHL/Pedestrian protection

30 —

31 Passenger window switch

32 —

33 Sunroof

34 Front wiper

35 Steering column lock

36 RBEC/Ignition

37 –/MIL/Ignition

38 Aeroshutter

39 O2 sensor/Emissions

40 Ignition coil/Injectors

41 –/Ignition coil/Injectors

42* Engine control module

43 —

44 —

45 Front Washer Relay

48 Instrument panel/Body/Ignition

49 FSCM/Ignition

50* Heated steering wheel

51* Engine control module/Ignition

52* TCM/Ignition

53 Coolant pump

55 —

56* TCM/–

64* Automatic headlamp leveling

65* Left HID headlamp

66 Right HID headlamp

67 High-beam headlamps

68 Headlamp leveling motor

69 Horn

71 Coolant fan

72 Starter 2

73* Brake vacuum pump

74 Starter

75 A/C clutch

76 —
